Product Description

NF-838 LCD Multifunction Cable Tester

Features:

1. troubleshooting for 5E, 6E, telephone, coaxial , USB , 1394 cables and other wires.

2. 5 kinds of cable can be trace located : RJ45/RJ11/BNC/USB/1394.

3. Hunt cable directly in connection with Ethernet switch/ router /PC terminal of different models in startup.

4. 9 different tones for different circuit status.

5. LCD light assists use in dark corners.

6. Earphone permits use in noisy environments.

Specifications:

NF-838 Transmitter specifications
Indictor	LCD 53x25 mm, with back light
Max. distance of transmission	2 km
Max. working current	Less than 70mA
Tone mode	9 Tone adjustable
Compatible connectors	RJ45(8pin),RJ11(2pin), BNC, USB, IEEE1394
Max. signal voltage	15Vp-p
Function and faults LCD display	LCD display ( wiremap, Tone, short, , No adapter, Low battery )
Cable map indication	LCD (#1-#8)
Shielded indication	LCD ( #9)
Battery Type	DC9.0V（NEDA 1604/6F22 DC9V x 1pcs）
Dimension (LxWxD)	185x80x32mm
NF-838 Receiver specifications
Frequency	455kHz
The Max. working current	Less than 70mA
Earjack	1
LED illumination	2
Battery Type	DC9.0V（NEDA 1604/6F22 DC9V) x1pc
Dimension (LxWxD)	218x46x29 mm
NF-838 Remote unit specifications
Compatible connectors	RJ45(8pin),RJ11(2pin),BNC,USB,1394
Dimension (LxWxD)	107x30x24mm
