| Max. cutting length | 100mm |
| Compressed Air Required | 0.6-0.7Mpa |
| Max. Section Size | 100×120mm |
| Min. Section Size | 20×40mm |
| Cutters Rotating speed | 10500 r/m |
| Cutters Fitting Diameter & Depth | φ 13mm×40mm |
| Max Cutting Width | ≦ 18mm |
| Cutting Angle | 0-90° |
| Cutter Motor | 1.1KW 2 Pole |
| Sliding Support Motor | 0.75KW 6 Pole |
| Overall Dimension | 3400×970×1250mm |
| Net Mass | 538Kg |
|
Slots Space (mm) 6.5-13-19.5-26-32.5-39-45.5-52-58.5-65-71.5-78-84.5-91-97.5mm When two pieces of wood are processed, the general rack length is 3.3m. |
|
| All rights for technical modifications reserved. CE approval | |
